Technical Specifications
- Battery Voltage: 12 V / 24 V / 48 (Auto Select).
- Rated Charge Current: 20 A.
- Nominal PV Power (12V): 290 W.
- Nominal PV Power (24V): 580 W.
- Nominal PV Power (48V): 1160 W.
- Max. PV Short Circuit Current: 20 A.
- Automatic load Disconnect: Yes, Maximum 20 A.
- Maximum PV Open circuit Voltage: 100 V.
- Peak efficiency: 98 %.
- Charge Voltage 'Absorption': 14,4 V / 28,8 V / 57.6V (Adjustable).
- Charge Voltage 'Float': 13,8 V / 27,6 V / 55.2V (Adjustable).
- Charge Algorithm: Multi-stage Adaptive.
- Temperature Compensation: -16 mV/°C resp.-32 mV/°C.
- Continuous Load Current: 20 A.
- Low Voltage disconnect: 11,1 V / 22,2 V / 44.4V or 11,8 V / 23,6 V / 47.2V or Battery Algorithm.
- Low Voltage reconnect: 13,1 V / 26,2 / 52.4V V or 14 V/ 28 V / 56V or Battery Algorithm.
- Protection: Battery reverse polarity (Fuse) / Output Short circuit/ Over temperature.
- Operating Temperature: -30 °C to 60 °C (full rated output up to 40 °C).
- Humidity: 95% Non-condensing.
- Data Communication: VE. Direct.
Enclosure
- Colour: Blue.
- Power Terminals: 6 mm² / AWG10.
- Protection Category: IP43.
- Weight: 0.65 kg.
- Dimensions: 100 mm x 113 mm x 60 mm.
